Vulcatherm Hot - Water 140 °C max - Heating power 14kW / 400V 3P - ?Pressurized circuit with mechanical expansion

Product N° : 10812.14
Temperature control units Vulcatherm Hot Water 10812 Vulcanic Vue1
search
  • Temperature control units Vulcatherm Hot Water 10812 Vulcanic Vue1
  • Temperature control units Vulcatherm Hot Water 10812 Vulcanic Draw
  • Opertaing curve of Vulcatherm Hot Vulcanic Draw

Vulcatherm temperature control unit for heating and regulating a closed water loop from 10°C to 140°C max intended for applications of autoclaves, sterilisers, mixers, melters, etc. Heating power 14 kW / 400 V 3P + E. Pressurization of the circuit at 3 bar.g with mechanical expansion by membrane expansion tank. max admissible pressure of 12 bar.g in the circuit.

Can be made , Under 21 days

Vulcatherm model :
Hot
Heat transfer medium :
Water
Type of heat transfer medium expansion :
Pressurisation to 3 bar.g with mechanical expansion (Via expansion tank)
Heating power (kW) :
14
Tolerance on heating power :
+5/-10%
Supply voltage :
400 V 3P + E
Maximum current absorbed at 400 V 3P (A) :
26
Maximum temperature of the heat transfer medium (°C) :
140
Minimum temperature of the heat transfer medium (°C) :
10
Maximum pressure allowed in the current (bar.g) :
14
Nominal flow of the heat transfer medium :
2.1 m3/h at delta P of 5.1 bar
Expansion volume (l) :
5
Medium inlet and outlet connections :
3/4'' female gas thread
Système de gestion centralisé (automate)
Integrated central management (controller)
Body material :
Painted frame equipped with castor
Vulcatherm dimensions (mm) :
L: 400 x H: 730 x D: 860
Weight (kg) :
100
